AS 3740 waterproofing

TL;DR: AS 3740-2021 is the Australian Standard the NCC points to for waterproofing domestic wet areas in Class 1 and Class 10 buildings. Get the substrate, the falls, the membrane upturns and the penetrations right. Use one tested system instead of mixing products. Check who is actually allowed to do the work in your state, and keep a signed certificate plus photos on file. Almost every leak that becomes a defects claim two years later traces back to a handful of repeatable mistakes, and they are all in this guide.

Waterproofing is the part of a build nobody sees once the tiler has finished, which is exactly why AS 3740 waterproofing gets rushed on too many jobs. The membrane goes down, it looks fine, the tiles go over the top, and the first sign of trouble is a stain on the ceiling below eighteen months later. By then the job is your problem again, your builder's warranty is on the hook, and proving what actually happened under the tiles is close to impossible.

That is the problem the standard exists to prevent. This guide covers what AS 3740 actually applies to, where it sits inside the National Construction Code, the details that cause most failures, who is legally allowed to apply a membrane in your state, what a missing certificate costs you when a claim lands, and how to make the checks part of your program instead of something you try to remember at lock-up.

What AS 3740 waterproofing actually covers

AS 3740-2021, published by Standards Australia, sets the minimum requirements for waterproofing and water-resistant treatments in domestic wet areas: bathrooms, showers, ensuites, laundries and WCs in Class 1 buildings (houses) and Class 10 buildings (sheds, carports and similar). The 2021 edition supersedes AS 3740-2010, so if you are working off a printed copy or a trade note from a few years back, check what you are holding.

It applies to renovation work as well as new builds. A bathroom reno in a 1970s brick veneer is caught by the same requirements as a new slab-on-ground house, even though the substrate is usually worse, the access is tighter and the existing falls are often wrong. That is not a discount. It is a harder job to make compliant, and it should be priced as one.

The standard tells you which surfaces need a fully waterproof membrane and which only need a water-resistant treatment, how far the waterproofing has to extend past the wet area itself, and how junctions, penetrations and hobs have to be detailed.

What it does not cover matters just as much. Swimming pools, commercial wet areas, and balconies or decks exposed to weather sit under different standards and different NCC provisions. If you are quoting a job with a rooftop terrace or a balcony above a habitable room, do not assume AS 3740 has you covered. Work out which standard applies before you price the scope, because external waterproofing is a different product set at a different rate, and getting that wrong in a quote is a margin problem before it is ever a compliance problem.

Key takeaway: AS 3740 is domestic wet areas only. Balconies, decks and anything exposed to weather are a separate scope, a separate standard and a separate line in your quote.

Where the standard sits in the NCC

AS 3740 is not law by itself. It becomes a compliance pathway because the National Construction Code references it as a Deemed-to-Satisfy provision for the Performance Requirements covering wet area waterproofing. In plain terms: follow AS 3740 properly and you are taken to have met the NCC's requirement to keep water out of the building fabric.

In the current NCC structure, the wet area provisions sit in Part 10.2 of Volume Two for houses and sheds, and in Part F2 of Volume One for apartments and other Class 2 to 9 work. Clause numbering shifted with the 2022 restructure and moves again between editions, so quote the clause from the edition your state has actually adopted rather than from memory.

You can also demonstrate compliance with a Performance Solution signed off by a building surveyor, but that is slower, costs more and puts a named professional's judgement in the middle of your program. For a standard bathroom there is no reason to take that path.

The NCC is free to read online at ncc.abcb.gov.au, which removes the only real excuse for guessing. AS 3740 itself is a Standards Australia publication and is paid, though many public and TAFE libraries hold read-only access. Because the Code updates on a cycle and states adopt on their own timelines, it is worth confirming which edition applies to your job. We have gone through the latest round volume by volume in our piece on NCC 2026 updates for Australian builders, which is a useful cross-check if you are not certain a wet area detail you have used for years still stacks up.

Substrate, falls and the membrane as a system

Compliance starts well before anyone opens a bucket. The substrate has to be sound, clean, dry and stiff enough that it will not crack the membrane later. Particle board and fibre cement sheet flooring both need the right fixing centres and joint treatment before anything goes over them, and a floor that flexes under a 90 kg tiler will flex under a 110 kg client in a shower.

Floors have to be graded so water runs to the waste rather than sitting in a corner. That fall belongs in the floor structure or the screed. It is not something the tiler can fix later by playing with adhesive bed thickness, and trying to is how you end up with a shower that holds a puddle 200 mm from the grate. The range usually quoted for a shower area is a fall between 1:80 and 1:50 to the waste. Confirm the figure in the edition in force for your job before you set a screed.

The membrane has to be a system. That means the primer, the membrane, the bond breakers and any reinforcing tape or fabric come from one tested, compatible range, not from whatever half-tins are left in the shed. Manufacturers publish system data sheets for exactly this reason. Mixing brands is one of the fastest ways to void a product warranty and end up with a membrane that delaminates inside a couple of years, and the manufacturer will say so in writing the moment you make a claim.

Enclosed shower floors are waterproofed in full, not just the patch under the rose. Walls are waterproofed to a height that depends on whether they are inside the enclosure or outside it, and on what the wall is made of. The figures you will hear on site are 1800 mm up a shower wall, a 150 mm upturn at wall and floor junctions, and 1500 mm measured out from the outlet for an unenclosed shower. Treat those as the shape of the requirement rather than the requirement. The extents change with the shower type and the substrate, and this is detailed enough that quoting it from memory is precisely how mistakes happen. If you are detailing a wet area without the standard or a manufacturer's system guide open in front of you, you are guessing.

Where defects start: upturns, penetrations and sealants

Most AS 3740 failures are not membrane failures in the middle of a floor. They are failures at the edges.

The membrane needs to turn up the wall at every wall and floor junction, continuously, with no section trimmed short because the plasterer's sheet finished a few millimetres low or the tiler was waiting. Hobs, step-downs and door thresholds are the same story. Any change of level or material is a place a membrane can be interrupted, and an interrupted membrane is not a compliant membrane.

Penetrations are the other repeat offender. Floor wastes, shower mixer bodies, pipe penetrations and any screw fixing through the substrate all have to be sealed as part of the system, using flanges, collars or the manufacturer's detail. A bead of silicone applied afterwards is not a detail, it is a hope. Every screw driven through a membrane to fix a hob, a niche or a frameless screen is a hole that needs treating, and on plenty of sites it simply is not.

Then there are sealants. Flexible sealant at internal corners and changes of plane is doing a different job from the membrane. It accommodates movement. Builders who treat silicone as a second membrane, or who let a tiler grout a movement joint solid, remove the one thing in the assembly designed to move. Specify the joints, show them on the tiling layout and inspect them before the screen goes in.

Key takeaway: If you only inspect two things, inspect the upturns and the penetrations. That is where the water gets in, and photographs of both are what you will wish you had in two years.

Who is allowed to do the work in your state

This is the part builders get wrong most often, because the answer is not national.

Queensland is the strictest. The QBCC runs a dedicated waterproofing trade contractor licence class, and building work above a dollar threshold (long held at $3,300 including GST and materials) requires a licence. In New South Wales, waterproofing falls under general residential building work licensing, with a threshold of $5,000 including GST, and the licence holder needs the relevant qualification behind it. Victoria registers waterproofing as a limited domestic builder category through the VBA, and domestic building work above $10,000 generally needs a registered builder. Other states and territories each draw the line differently again.

Thresholds and category names move, and they have moved more than once in the last few years. Treat those figures as a prompt to check with your state regulator, not as advice. The practical rule is simpler: before you let anyone apply a membrane on your job, see the licence or registration, see that it covers waterproofing, and see that it is current. Take a copy. An unlicensed applicator does not just create a compliance problem for them. It creates an insurance problem for you, because home warranty insurers and defect liability both run through the licensed builder.

AS 3740 waterproofing and your defect liability

Waterproofing is the worst kind of defect to carry, because the damage is slow, hidden and expensive to prove. By the time it shows, the tiles, the screed, the wall sheeting and often a ceiling below all have to come out, and nobody can say with certainty whether the membrane was wrong, the falls were wrong or a screw went through it.

Statutory warranty periods make that asymmetry worse. Most states separate structural or major defects from minor ones, with roughly six years for the first bracket and two for the second, and several jurisdictions treat waterproofing failures as a major defect. That puts a shower built in 2026 inside your liability window well into the 2030s. We have set out how the brackets work state by state in our guide to construction defect liability in Australia, including what a claim actually looks like when it arrives.

The only defence that holds is a record made at the time. That means:

  • A waterproofing certificate from the applicator, naming the products used, the areas covered, the number of coats and the dates of each.
  • The licence or registration number of whoever applied it.
  • The manufacturer's system data sheet for the products named, not a generic brochure.
  • Dated photos of the primed substrate, the finished upturns, every penetration and the flood test if one was done.
  • The tiler's sign-off that they did not penetrate the membrane, and a note of any fixings that were sealed.

That file costs about fifteen minutes per bathroom to assemble while the trades are still on site. Reconstructing it four years later costs an expert report.

Build the check into your program, not your memory

Waterproofing sits in the worst spot in a build program. It falls between trades, it holds up the tiler, and it happens in the week everyone is chasing the slab for the next job. That is why it gets compressed. Membranes need their stated cure time between coats and before tiling, and a membrane tiled over early fails in a way that looks identical to a membrane applied badly.

Treat it as a hold point rather than a task. Book the inspection as its own line with its own duration, put the cure time in as real days instead of slack, and attach the photo requirement to the inspection so the record gets made by the person who is already standing there.

That is just document discipline, and a phone does it better than a ute console full of paperwork. We compared the tools builders actually keep using in our rundown of the best construction apps for Australian builders, and the pattern is consistent: the app that gets used is the one that takes five seconds on site, not the one with the most features. The same logic applies to pricing the scope properly in the first place, which is why waterproofing deserves its own line in your estimate rather than being absorbed into a tiling allowance. If you are still doing that in a spreadsheet, the options are worth a look in our piece on construction estimating software.

Frequently asked questions

Does AS 3740 apply to a bathroom renovation, or only new builds?
Both. A renovation is caught by the same requirements. In practice it is the harder job, because you inherit the substrate, the falls and whatever the last builder did, and you often cannot see any of it until demolition.

Do I need a licensed waterproofer?
It depends on your state and the value of the work. Queensland has a dedicated waterproofing licence class, New South Wales and Victoria handle it through residential building licensing and registration above a value threshold. Check with your state regulator, then sight and copy the licence before work starts.

How high does waterproofing go up a shower wall?
1800 mm is the figure most commonly quoted for walls inside a shower enclosure, with a 150 mm upturn at wall and floor junctions elsewhere. The actual extent depends on the shower type and the substrate, so take it from the current edition of AS 3740 or the manufacturer's system guide rather than from a rule of thumb.

Does AS 3740 cover balconies and decks?
No. External waterproofing of balconies, decks and anything exposed to weather sits under separate NCC provisions and separate standards. Price it separately.

Is AS 3740 free to read?
The NCC is free at ncc.abcb.gov.au. AS 3740 is a Standards Australia publication and is paid, available through standards.org.au, though many libraries hold read-only access.

What if the waterproofing certificate is missing?
You are not automatically non-compliant, but you have lost your evidence. If a leak appears inside the warranty period the burden of showing the work was done properly falls on you, and without a dated record it becomes an argument between experts.

Does a flood test prove compliance?
It proves the membrane held water on the day it was tested, which is worth having. It does not prove the upturn heights, the product compatibility or the cure times were right. Keep the test, and keep the rest of the record too.

One less thing to remember at lock-up

Nothing here is complicated. It is a small number of details that have to be right, checked by someone while the work is still visible, and recorded somewhere you can find it years later. The builders who get burned by waterproofing are almost never the ones who did not know the requirement. They are the ones who knew it and had no record of having met it.
